Brief introduction Product Features
*Size:120(L)*120(W)*0.8(H)mm *1.Gain 6dBi;
*Frequency:902～928MHz *2. Small Size, Superior performance, high cost-effective;
*Gain:6dBi *3. PCB Material
*Polarization: Circular *4. widely used in asset, warehouse management system
*Weight :about 0.18KG
Specification
Model Number
RL-AP6
Performance
Index
Input impedance
50Ω
VSWR
≤1.5
Connector
SMA Female
Axial ratio
<2
Beamwidth-°
>40
Direction wave figure
3dB beamwidth
Mechanical Performance Index
Color
Black
Material
PCB
IP Grade
IEC IP-67
Work Temperature
-40ºC to+60ºC
Storage Temperature
-40°C to+80°C
